NTK CSVB Series Carbide Turning Inserts for CNC Back Turning Operations
CSVB Application Field
The CSVB is a widely used type of CNC carbide back turning insert. This replaceable insert is securely gripped in a turning tool body that mounts onto the lathe turret. It is primarily designed for turning and cutting small steel parts, available in various shapes and cutting angles.
Production Standard
These inserts primarily reference the NTK CSVB series standards. Specific size details can be customized based on customer requirements. The CSVB series is a sub-series of the well-regarded CSV series of carbide back turning inserts. Our Drow standard production sizes and stock specifications are aligned with this NTK series.
For detailed specifications, refer to the section below.
Product Details: CSVB
-
Material Quality: Made from 100% original carbide powder, ensuring outstanding wear resistance and toughness.
-
Dimensions:
- Width (W): 1.0–1.4 mm
- Angle (α): 0.15 or 0.30 mm
-
Coating Technology: Advanced coatings are tailored to your application, enhancing corrosion and wear resistance.
-
Fine Grinding Process: The insert's surface achieves high smoothness and excellent cutting edge quality, minimizing cutting resistance and friction loss.
-
Perfect Fit: Accurately designed edge strips reduce the likelihood of micro-vibration during processing.
-
Applicable Materials:
- Uncoated Inserts: Ideal for aluminum, non-ferrous metals, and non-metallic materials.
- Coated Inserts: Suitable for carbon steel, alloy steel, mold steel, hardened steel, and ductile iron.
-
Customization: If standard stock does not meet your needs, please provide CAD or 3D drawings for your inquiry.
-
Production Quality: All inserts are produced using high-end EU processing equipment. For more details, refer to the “Entire Production Quick View” section.
Product Features:
- Edge Protection: Chamfering and tip-arc processing enhance the durability of the cutting edge, preventing fractures and ensuring a smooth workpiece finish.
- Precision Machining: Utilizes Swiss 5-axis machines for processing R angles and includes passivation treatment.
- High-Performance Coating: Composite coatings provide a super hard and smooth surface, optimizing cutting performance.
- Efficient Chip-Breaker Design: Engineered for optimal cutting efficiency across various applications.
- Precision Engineering: High accuracy and burr-free dimensions ensure a perfect fit in tool holders, minimizing micro-vibration during operation.
- Superior Material: Base materials imported from Europe provide enhanced oxidation and wear resistance.
- Custom Insert Options: Available in various dimensions, coatings, chip-breakers, and material grades.
Carbide inserts produced by We Drow ensure efficient machining and extended tool life, receiving positive feedback around the world.
Product Specification:
| Part Number |
W1 |
S |
D1 |
| CSV_ |
3 |
8.7 |
5 |
| Part Number |
Dimensions(mm) |
| Chipbreaker |
W |
α |
β |
θ |
rε |
| Back Turning CSVB_ |
11FR/L V |
N |
1.00 |
0.30 |
5° |
45° |
0.0 |
| 11FR/L V-A |
1.00 |
0.30 |
2° |
45° |
0.0 |
| 11FR/L V-M |
1.00 |
0.15 |
2° |
45° |
0.0 |
| 11FR/L V-C |
1.00 |
0.15 |
5° |
45° |
0.0 |
| 11FR/L V-12 |
1.20 |
0.30 |
5° |
45° |
0.0 |
| 11FR/L V-14 |
1.40 |
0.30 |
5° |
45° |
0.0 |
| 11FR/L VB |
Y |
1.00 |
0.30 |
5° |
45° |
0.0 |
| 11FR/L VB-A |
1.00 |
0.30 |
2° |
45° |
0.0 |
| 11FR/L VB-M |
1.00 |
0.15 |
2° |
45° |
0.0 |
| 11FR/L VB-C |
1.00 |
0.15 |
5° |
45° |
0.0 |
| 11FR/L VB-12 |
1.20 |
0.30 |
5° |
45° |
0.0 |
| 11FR/L VB-14 |
1.40 |
0.30 |
5° |
45° |
0.0 |
| Attention:The above are our standard production size and standard stock specifications, the size details can be processed separately according to customer requirements, and refer to the standard: NTK's CSVB series, etc. |
