TBP 60FR-20 Carbide Turning Inserts for CNC Lathe Steel Parts Machining with and Smooth Cutting Operations
TBP Application Field
The TBP series represents a popular type of CNC carbide back turning insert, primarily utilized for turning and cutting operations on CNC lathes and machines. These inserts are available in various shapes and cutting angles, making them versatile for different applications.
When selecting a turning insert, consider several parameters, including geometry, grade, shape (nose angle), size, nose radius, and entering (lead) angle. Careful selection ensures optimal chip control and machining performance:
- Insert Geometry: Choose based on the operation, such as finishing.
- Nose Angle: Opt for the largest possible angle for enhanced strength and economy.
- Insert Size: Select according to the depth of cut.
- Nose Radius: A larger radius generally improves strength; use a smaller radius if vibrations are an issue.
Production Standard
This series of inserts primarily follows the NTK TBP series standards. Specific size details can be customized based on customer requirements. Our Drow standard production sizes and stock specifications refer to this well-known NTK series.
For detailed specifications, please see the section below.
Product Details: TBP
-
Material Quality: Made from 100% original carbide powder, ensuring excellent wear resistance and durability.
-
Dimensions:
- Effective Length (a): 3.0–4.8 mm
- Nose Angles (θ): 60° or 55°
- Nose Radius (γε): 0.00–0.20 mm
-
Coating Technology: Advanced coatings are defined per your application, enhancing corrosion and wear resistance.
-
Fine Grinding Process: The high smoothness of the insert surface leads to improved cutting edge quality and reduced resistance, minimizing friction and wear.
-
Perfect Fit: Accurate edge strips ensure minimal micro-vibration during processing.
-
Applicable Materials:
- Uncoated Inserts: Ideal for aluminum, non-ferrous metals, and non-metallic materials.
- Coated Inserts: Suitable for carbon steel, alloy steel, mold steel, hardened steel, and ductile iron.
-
Customization: If standard options do not meet your requirements, please provide CAD or 3D drawings for inquiries.
-
Production Quality: These carbide inserts are manufactured using high-end EU processing equipment. For more production information, refer to the “Entire Production Quick View” section.
Product Features:
- Edge Protection: Chamfering, passivation treatment, and tip-arc processing enhance the cutting edge's durability, preventing fractures and ensuring smooth workpiece surfaces.
- High-Performance Coating: Composite coatings provide a super hard and smooth surface, optimizing machining efficiency.
- Efficient Chip-Breaker Design: Designed for optimal cutting performance across various applications.
- Precision Engineering: High accuracy and burr-free dimensions ensure a perfect fit in tool holders, reducing micro-vibration during operation.
- Superior Material: Base materials imported from Europe offer improved oxidation and wear resistance.
- Custom Insert Options: Available in various dimensions, coatings, chip-breakers, and material grades.
Carbide inserts produced by We Drow deliver efficient machining and extended tool life, receiving positive feedback worldwide.
Product Specification:
| Deseription |
Dimension(mm) |
| θ |
γε |
Effective Length a(mm) |
Cutting depth(mm) |
| TBP_ Series N |
60FR/L 00 |
60° |
0.00 |
3.7 |
5.3 |
| 60FR/L 10 |
60° |
0.10 |
3.7 |
5.3 |
| 60FR/L 20 |
60° |
0.20 |
3.7 |
5.3 |
| 55FR/L 00 |
55° |
0.00 |
3.0 |
5.3 |
| 55FR/L 10 |
55° |
0.10 |
3.0 |
5.3 |
| TBP_ Series V |
60FR/L V |
60° |
0.00 |
4.8 |
5.3 |
| 60FR/L V05 |
60° |
0.05 |
4.8 |
5.3 |
| 60FR/L V10 |
60° |
0.10 |
4.8 |
5.3 |
| Attention:The above are our standard production size and standard stock specifications, the size details can be processed separately according to customer requirements, and refer to the standard: NTK's TBP series, etc. |
Entire Production Quick View
- Utilize 100% original carbide powder to create the integral insert blank through sintering.
- Perform flat grinding machining.
- Execute surrounding grinding machining.
- Create the insert cutting edge.
- Conduct chamfering and tip-arc processing of the cutting edge.
- Apply composite coatings.
Quality Inspection
- Thoroughly checked by experienced personnel.
- Microscope examination for precision verification.
- Projector detection for dimensional accuracy.
- Verification of edge passivation.
Why choose us:
1.Technical innovation: Complex surfaces and functional structures can be quickly formed and kept accurate.
2.Processing speed: Short production cycle, fast delivery time, to ensure delivery on time according to the delivery date.
3.Product quality: High quality guaranteed.High precision, up to 0.005-0.001mm.
4.Confidentiality system: Triple confidentiality measures to protect, proofing more assured.
5.Fully equipped: Excellent processing capacity, multiple production lines, advanced equipment, professional supporting facilities.
6.Cost-effective: Reasonable design and material selection lead us to a competitive price, so that could help provide you more favorable price of the same level products .
FAQ
Q1:If we want to cooperate with you, is it possible to get confidentiality?
A: Sure, all your information including company info, drawings, PO details will be kept confidential, we can signed NDA if you want (non disclosure agreement).
Q2: What is your terms of payment?
A: T/T 30% as deposit, and 70% balance before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3: How can we trust your product quality?
A: 100% products quality inspection for first batch, and casual inspection for the coming batch.Raw material will be tested before bulk production and we will check the physical properties, shape and tolerance for ensuring qualified products before shipping
Q4: What else can you buy from us?
A: Carbide insert,carbide end mill,carbide drill,carbide boring,cutting tools&customized carbide precision molds.
Q5: Can we get a discount if our ordered quantity is big enough ?
A: Yes. If your ordered quantity is big enough , we can offer you our best price and will give you a discount.
Q6. Could you offer OEM and ODM service?
A:It’s okay , we have more than 10 years experience in OEM service.Our professional R&D team is dedicated to design products to fit various demands of customers. They can always offer the professional advice and solutions for you!
Q7:Do you accept low volume for sample order? And what’s your MOQ for special tools?
A: Yes, we do. For sample order, MOQ one piece is accepted, and the sample lead time is 2-3 days. It can be negotiated for special requirement.
Q8: What's your delivery way?
A: According to the requirements of customers,we will provide the best transportation service
