High Precision DCGT11T302 Carbide Turning Inserts for CNC Machining and Metal Parts Finishing

DCGT11T302 Application Field

The DCGT11T302 is a type of CNC carbide turning insert primarily used for external turning and cutting operations on CNC lathes and machines. These carbide inserts are replaceable and typically indexable, made from cemented carbide, and suitable for machining steels, cast iron, high-temperature alloys, and nonferrous materials. They facilitate faster machining and produce superior finishes on metal parts. For specific dimensions, please refer to the “ISO Turning Inserts Naming Rules.”

When selecting a turning insert, consider various parameters, including insert geometry, grade, shape (nose angle), size, nose radius, and entering (lead) angle. Careful selection is crucial for optimal chip control and machining performance:

• Insert Geometry: Choose based on the operation, e.g., finishing.
• Nose Angle: Opt for the largest possible angle for enhanced strength and economy.
• Insert Size: Determine based on the depth of cut.
• Nose Radius: Select a larger radius for strength; a smaller radius may be needed if vibrations are a concern.

ISO Turning Inserts Naming Rules:

Product Details: DCGT11T302

• Material Quality: Crafted from 100% original carbide powder, ensuring excellent wear resistance and toughness.

• Dimensions: Complies with ISO standards.

• Coating Technology: Advanced coatings tailored to your application, enhancing corrosion and wear resistance.

• Fine Grinding Process: The insert surface boasts high smoothness, excellent cutting edge quality, and minimal cutting resistance, effectively reducing friction and wear.

• Perfect Fit: Accurate and smooth insert edge strips minimize micro-vibration during processing.

• Applicable Materials:

  • Uncoated Inserts: Suitable for aluminum, non-ferrous metals, and non-metallic materials.
  • Coated Inserts: Effective for carbon steel, alloy steel, mold steel, hardened steel, and ductile iron.

• Customization: If standard options do not meet your requirements, please provide CAD or 3D drawings for inquiries.

• Production Quality: All inserts are produced using high-end EU processing equipment. For more details, please refer to the “Entire Production Quick View” section.

Product Features:

1. Edge Protection: Chamfering, passivation treatment, and tip-arc processing enhance the insert's durability, preventing fractures and ensuring smooth workpiece surfaces.
2. High-Performance Coating: Composite coatings provide a super hard and smooth surface, optimizing performance.
3. Efficient Chip-Breaker Design: Engineered for perfect cutting performance across various applications.
4. Precision Engineering: High accuracy and burr-free dimensions ensure a flawless fit in tool holders, reducing micro-vibration during operation.
5. Superior Material: Imported base materials from Europe offer improved oxidation and wear resistance.
6. Custom Insert Options: Available in various dimensions, coatings, chip-breakers, and material grades.

Carbide inserts produced by We Drow deliver efficient machining and extended tool life, receiving positive feedback globally.

Product Specifications

Note: The sizes listed are standard production specifications. Custom processing can be arranged based on customer requirements.

Entire Production Quick View

1. Utilize 100% original carbide powder to create the integral insert blank through sintering.
2. Perform flat grinding machining.
3. Execute surrounding grinding machining.
4. Create the insert cutting edge.
5. Conduct chamfering and tip-arc processing of the cutting edge.
6. Apply composite coatings.

Quality Inspection

1. Thoroughly checked by experienced staff.
2. Microscope examination for precision verification.

Why choose us:

1.Advanced Technology: Complex surfaces and functional structures can be quickly formed and kept accurate.
2.Short Machining Period: Short production cycle to ensure delivery on time according to the delivery date.
3.Crowned Product: High quality guaranteed.High precision, up to 0.005-0.001mm.
4.Confidentiality System: Triple confidentiality measures to protect customer’s private design. Proofing more assured.
5.Fully Equipment: Excellent processing capacity, multiple production lines, advanced equipment, professional supporting facilities.
6.Cost-effective: Reasonable design and material selection lead us to a competitive price, so that could help supply customers cheaper price of the same level products .

FAQ

Q1: What is your terms of payment?
A: T/T 30% as deposit, and 70% balance before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q2: How can we trust your product quality?

A: 100% products quality inspection for first batch, and casual inspection for the coming batch.Raw material will be tested before bulk production and we will check the physical properties, shape and tolerance for ensuring qualified products before shipping
Q3:Do you accept low volume for sample order? And what’s your MOQ for special tools?
A: Yes, we do. For sample order, MOQ one piece is accepted, and the sample lead time is 2-3 days. It can be negotiated for special requirement.

Q4: How do you keep long-term and good relationship with our business?
A:1. Consistent quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend. We sincerely do business and make friends with them, no matter where they come from.

Q5:Are you a factory or trading company?
A1: We are a professional manufacturer of precision hardware tools industry for tens of years. Welcome to visit our company.We guarantee our products are factory price, very cheap and competitive.

Q6. Can you send products to our Forwarder in China?

A: Yes,if you have Forwarder in China,we will glad to send products to him/her.

Q7:Is your company accept customization?

A: OEM and ODM are available. And we have our own professional R&D team servicing for you.
